About Company
TRIDENT SERVICES
is a Young and Growing Company which mainly provides Post Tension Detailed Drawings. As a company we might be a start-up but we have an experienced
team of skilled and talented professionals having work experience of more than 7 years in Post tension field. “Quality within time is our Priority” because when Time and Quality are administered efficiently, great things
happen.
OUR SERVICES
We provide different types of services related to Post Tension.
OUR CASE STUDIES
The Following case studies are based on imaginary scenario. These structures do not exist in real life as shown.
POST TENSION GIRDER
There are two different force holders, post tension girders with Longitudinal Section. Profiles are separated and detailed into two and three layers. The most Engrossing part of these profiles is separation of stages of stressing into two and three parts. According to force, Anchor Plates, Tendon grouping and other details are configured.
There are two different force holders, post tension girders with Longitudinal Section. Profiles are separated and detailed into two and three layers. The most Engrossing part of these profiles is separation of stages of stressing into two and three parts. According to force, Anchor Plates, Tendon grouping and other details are configured.
View all SheetsONE-WAY POST TENSION SLAB
There are 3- sheets for tendon layout details, 2- sheets for support details, and 2- sheets for beam details (total 7- sheets.)
Tendon layout detail sheets are namely, Uniform tendons layout, Beam tendon layout, temperature
tendon layout. In which you will find placements of tendons and tagging of tendons (i.e. Grouping, color code, numbering etc) excluding tendon schedule. Further in tendon support layout sheets are detailed in such a way
that chair height & CGS texts are configured in well manner (easy to read). In Beam End View Details with backup bars you will find anchor placement is clear and well positioned. In this part, we have placed great emphasis
on profile And End Views details of multiple married beams with section details.There are 3- sheets for tendon layout details, 2- sheets for support details, and 2- sheets for beam details (total 7- sheets.) Tendon layout
detail sheets are namely, Uniform tendons layout, Beam tendon layout, temperature tendon layout. In which you will find placements of tendons and tagging of tendons (i.e. Grouping, color code, numbering etc) excluding tendon
schedule.
TWO-WAY POST TENSION SLAB
In this part, there are 2-sheets for tendon layout & 2- sheets for support layout (excluding tendon schedule).
Here you will find two way post tension complex structure including :
post tension beam slab fold,
Drop Cap,
Ramp etc.
are configured in detail.
In this our aim is for presenting following:-
Flaring of Beam Tendons into slab, Longitudinal & Cross-sectional Details, Anchor Placements, and Beam Tendon Profile
at Slab Fold with End Views.
REBAR CALCULATION OF TWO-WAY POST TENSION SLAB
In Rebar calculation, we have taken or considered 3- base sheets from Two-way Post tension Slab (previous case study). Details are described below;
Calculations Of backup bars for banded tendons & uniform tendons with
summary of Anchorage Hairpin are shown in 1st sheet.
Banded Tendons support bar & uniform tendons support bar computation are shown in 2nd & 3rd Sheet respectively.
In this portion our main aim is to present our
Depth of Detailing and Types of Backup bar we have used (L or C shape) Lap length Determination, Chair Take off & Other Details.
Why Choose us
Accuracy
We follow 3 layered checking procedure to eliminate every minute mistake from the final product.
Work force
Skilled team of Engineers are main building blocks with that we are going to accomplish our goals.
Versatility
In today's world full of Customisation, we understand client's needs. we work in FPS as well as Metric unit systems as per requirements.
Time
We Value the Time of our Clients. Every project is managed by using PERT to maintain deadlines.
Advanced Designs
Self-Made programme to calculate chair height to get accurate and faster results.
Our Working process
Essential Documents
We required Latest Structure & Architect Drawing set of Project Including Pour Break and regular Updates on revisions (if any).
Provision of JIS & Submittal Schedule
(Next day after Receiving documents) We issue Job Information Sheet (JIS) Assuring all Standards related to Job & Submittal Schedule.
Draughting & Validation
(Within 6 Days) After Authenticating, Draughting & Supervision will be done in Three Quality check stages Including last stage of Securing Shop Drawing with Relevant Codes & Standards.
Delivery of Shop Drawings
Finally Shop Drawing will be Deliver to you.
